One Arm Welding Fume Extractor , 80W solder smoke absorber Purifier in Soldering

Shenzhen New Oxygen Purification Technology Co., Ltd.
Contact Now

One Arm Welding Fume Extractor , 80W solder smoke absorber Purifier in Soldering

  • 1
  • 2

Brand Name : Waterun

Model Number : F6001

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD 215-310 /set

Payment Terms : T/T, Paypal, MoneyGram, Western Union

Supply Ability : 5000pcs per month

Delivery Time : about 7-10 working days after received TT payment

Packaging Details : carton size: 55 x 35 x 58cm; gross weight: 18kgs

Product Name : Welding Fume Extractor

Application : soldering, laser marking & carving, etc

Noise : less than 52 dB

Duct Diameter : 75mm or 55mm

Voltage/Power : 110V-220V 80W

Systemic flow : 235m3/h

Filtering efficiency : 99.97% 0.3micron

Surface color : dark grey

Contact Now

One Arm Welding Fume Extractor , 80W solder smoke absorber Purifier in Soldering

Specifications:

Model:

F6001

Brand: Waterun

Filters:

pre-filter, Middle filter, active carbon filter

Voltage/Power:

110V / 220V

Power: 80W

Systemic Flow:

235m3/h

Air Velocity: 17m/s

Filtering Efficiency:

0.3micron 99.97%

Length of Duct:

dia. 75mmx1.4M or 55mmx1.2M

Noise:

< 52dB

Dimensions:

425 x 250 x 410mm

Net weight:

14kgs

Summary:

Waterun Fume Purifying and Filtering System is for cleaning of both particles and gases. It is designed to filter the harmfull substances, such as hydrocarbon and cyanide, during the process of soldering, tin dipping in the solder pot, laser marking and carving, printing, etc. It catches harmful smoke with freestanding ducts and adjustable air volume to significantly improve your working environment.

It has a triple-filter system:

1) Pre-Filter: the large-size pad filter can filter large particles of dust

2) Middle Filter: it filters the bigger powders for prolonging the main filter's life.

3) Main Filter: it includes HEPA (high efficiency) filter and gas filter. The HEPA cleans the gas and powders filtering from the pre-filter and then carry them to the gas filter. which with the carbon and other chemical combination, filters off the deleterious substance and then outputs the clean air.

Features:

1, Metal body structure, strong and durable;

2, Noise reduction design, quiet operation;

3, Triple-filter design ensures thorough purification;

4, High-quality alloy fan achieves great suction power.

Picture show:

One Arm Welding Fume Extractor , 80W solder smoke absorber Purifier in Soldering

Package:

One Arm Welding Fume Extractor , 80W solder smoke absorber Purifier in Soldering

Competitive Advantage:

1. Self-developed impeller, better quality than ordinary plastic impeller, more stable, more powerful suction. The unique tiered filter design, can effectively purify the toxic and harmful substances in the air, such as formaldehyde, benzene, ammonia, radon gas, sulfur dioxide..etc, and use of low cost.

2. The products from abroad mainly purify the viruses and bacteria as the main direction of governance. In China not only to purify viruses, bacteria, but also clean harmful smoke pollution. WHO estimates that there are over 200 million people deaths each year due to inhalation of indoor and outdoor air pollution in small particles.

3. Our company uses a brushless motor, compare with the ordinary motor, this motor speed is higher, lower noise, it does not require maintenance, but longer product life span.

FQAs:


1. What’s the advantage compare with ducted exhaust fan?
Answer: 1. Many advantages like (1) Clean the air quality (2) energy saving (3) easy installation, flexible remove (4) low cost (5) reduce the incidence of diseases and major diseases, and health is priceless (6) to reduce unpleasant smell (7) to reduce dust and other harmful substances, and so on.


2. What’s the life span of our fume extractor?
Answer: Motor lifetime is (continuous working 24 hours) 20,000 hours, consider environmental factors. Usually it can use 4-5 years without any problems.


3. What’s the best distance between the nozzle and the smokes?
Answer: The distance to be 5-15cm is the best.


4. The ducts for the fume extractor can be shortened or lengthened?
Answer: It can be shortened or lengthened appropriate; but we suggest not more than 1.5meter. For multi-station, the total pipe length should not exceed 10 meters.
